Power Point & Socket Installation, Repair & Replacement Singapore

In Singapore, “power point” and “socket” mean the same thing — the Type G 13A square-pin outlet on your wall. We use both words on this page (and across our site) for that reason. If you need a new one added, an old one replaced, or a cracked / loose / sparking one repaired, this is the right page.

At TRUST ELECTRICIANS, we install, repair, and replace power points and sockets for HDB flats, condominiums, landed houses, offices, retail shops, and F&B outlets across Singapore. All work uses EMA-approved, BS-1363-compliant 13A sockets rated for Singapore’s 230V / 50 Hz supply, fitted to Singapore Standard CP5.

✅ BCA Registered ✅ LEW-Certified ✅ EMA-Compliant ✅ HDB / Condo / Landed / Commercial ✅ Same-Day or Next-Day Slots ✅ Licensed & Insured

Adding a New Power Point / Additional Socket

Sometimes you simply need one more socket in a spot the original builder did not plan for — behind the new TV, beside the study desk, on the kitchen island, next to the bed. We add new power points in three common ways:

Surface-mounted (with trunking) — the fastest and cleanest option. We run a slim PVC trunking on the wall surface from the nearest existing socket or DB, and fit a new 13A outlet. Ideal for HDB, rental flats, and any place where you cannot or do not want to break the wall.
Concealed (chase into wall) — we cut a narrow channel in the plaster or brick, run the cable inside, and make good. Best for renovations and for HDB / condo owners who want the cleanest finish. Slightly more dust and noise, but invisible once plastered and painted.
From existing spur — if there is already a 13A socket nearby, we can sometimes run a new spur cable from it to a new location. Fastest, cheapest, but only works where the existing circuit has spare capacity.

For HDB and most condos, we always check the circuit’s current load first. A 20A circuit (typical for HDB power sockets) can safely feed about 4–5 sockets under normal use. If we are adding the 6th, we may need to run a fresh circuit from the DB.

Typical add-a-power-point time: 1–3 hours depending on the route, wall type, and whether a new circuit is needed.

"Over 2500+ Water Heater Safely Install & Replace Across Singapore"

⭐⭐⭐⭐⭐ 4.9/5 Google Rating

“Needed to replace our old water heater. Technician came on time and got it done quite quickly. Good workmanship and no mess left behind.”⭐⭐⭐⭐⭐

Jason Tan

“Our water heater stopped working, so we contacted them for a replacement. Response was fast and the whole process was smooth. Recommended.”⭐⭐⭐⭐⭐

Mich Lim

“Had an instant heater installed for my HDB unit. Technician was friendly and explained what was needed before starting. Good service overall.”⭐⭐⭐⭐⭐

Daniel Wong

“Very happy with the installation. The technician arrived as arranged, did the work neatly and tested everything before leaving. Thanks!”⭐⭐⭐⭐⭐

Cheryl Tan

“Replaced our old storage heater. Quite straightforward and the technician was professional throughout. Price was reasonable too.”⭐⭐⭐⭐⭐

Andrew Lee

“Called them for water heater installation. Response was quick and appointment was easy to arrange. Installation was done properly. Good experience.”⭐⭐⭐⭐⭐

Stephanie Ng

“Our heater was giving problems and we weren't sure whether to repair or replace it. They checked it and explained the options clearly. Appreciate the honest advice.”⭐⭐⭐⭐⭐

Kevin Lim

“Needed a new water heater urgently. Technician managed to come down quite fast and completed the replacement without any issues. Good service.”⭐⭐⭐⭐⭐

Rachel Wong

“Installed a new instant water heater at our condo. Technician was punctual, polite and cleaned up after the job. Happy with the service.”⭐⭐⭐⭐⭐

Marcus Lim

"Good service from start to finish. Quotation was clear and there were no surprises during the installation. Would use them again." ⭐⭐⭐⭐⭐

Elaine Lim

“Had our old heater replaced today. Everything was handled quite smoothly and the technician explained the work before starting. Recommended.”⭐⭐⭐⭐⭐

Ryan Koh

“Very convenient to arrange the appointment. Technician came on time and finished the installation quickly. Heater is working well now.”⭐⭐⭐⭐⭐

Grace Tan

“Needed a storage heater replacement for our home. Good workmanship and the technician was quite knowledgeable. Overall a pleasant experience.”⭐⭐⭐⭐⭐

Benjamin Lee

"Water heater was leaking and needed to be replaced. They responded quickly and arranged the replacement without much hassle. Good job."⭐⭐⭐⭐⭐

Amanda Ng

“Engaged them for water heater installation. Professional service, clear communication and neat work. No complaints so far.”⭐⭐⭐⭐⭐

Jonathan Lim

Socket Repair & Replacement (Cracked, Loose, Sparking)

Most socket problems fall into one of these four buckets, and all are repairable on the same visit:

Cracked or broken face plate — usually a mechanical impact (moving a sofa, a vacuum cleaner bump). We replace the face plate and check the back wiring.
Loose socket (plug falls out) — the internal grip has worn out. We replace the socket mechanism (or the full plate if it is one piece).
Sparking or small flash when plugging in — almost always loose back-terminal screws or a worn mechanism. We re-terminate, replace the socket, and test under load.
Burnt or discoloured socket — the most serious of the four. Caused by sustained arcing or overload. We replace the socket, inspect the cable, and re-test the circuit. If the cable insulation is heat-damaged, we may need to replace a section — see our Electrical Wiring Repair page.

⚠️ If a socket is hot to the touch, or smells burnt even when nothing is plugged in, stop using it immediately and call us. That is a precursor to an electrical fire.

13A vs 15A vs 3-Pin vs Universal

Singapore uses a few different socket formats, and choosing the right one matters:

13A, BS-1363 (Type G) — the standard square-pin socket you see in every HDB and condo. Used for everything from kettles to TVs. All our replacements are 13A unless you specifically ask otherwise.
15A round-pin (Type M) — used for some air-conditioning units, larger water heaters, and certain commercial equipment. If your aircon spur currently has a 15A round-pin socket, you should keep it 15A. We carry 15A sockets in stock.
3-pin Type I (Australia / China style) — uncommon in Singapore residential, but seen in some commercial / industrial equipment. We supply and fit these on request.
Universal sockets — accept a wide range of plug types. Useful for guest rooms, rental properties, and home offices with imported equipment. We supply Clipsal and Schneider universal variants rated for Singapore’s 230V supply.

If you are unsure which type you currently have, send us a photo and we will tell you on WhatsApp.

1-Gang / 2-Gang / 4-Gang Socket Options

The “gang” count is just how many sockets fit on one face plate. Picking the right one is a balance between convenience and circuit capacity:

1-gang — one socket per plate. Most common for new builds in HDB and condo. Cleanest look.
2-gang — two sockets per plate. The most popular in Singapore homes. Saves wall space.
3-gang — three sockets per plate. Often used in kitchens and behind TVs.
4-gang — four sockets per plate. Useful for media walls and home offices.

Important: A 4-gang socket is not the same as 4 separate circuits. It is one socket, just with 4 outlet positions. The total current it can safely supply is still limited by the cable feeding it. If you need 4 sockets drawing simultaneously at high load, we will usually recommend 2 × 2-gang on 2 separate circuits instead.

USB & Pop-Up Sockets

For bedrooms, kitchen islands, study desks, and conference tables:

USB-integrated sockets — a standard 13A socket with 1 or 2 USB-A / USB-C ports built in. Charges phones and tablets directly, freeing the 13A outlet for higher-draw devices. We supply Schneider, Legrand, and Clipsal variants.
Pop-up sockets — hidden inside a kitchen island or desk, push down to open, push again to close. Available with USB-A, USB-C, and 13A outlets. Particularly popular in new condo and landed renovations.

We will tell you upfront which brand / model is the best value for the use case, and we always confirm your USB cable wattage requirements (a 5W phone charger cable is fine on a 2.4A USB port; a 65W laptop charger needs USB-C PD).

Aircon Power Point & Isolator Installation

Air-conditioner spurs in Singapore are typically a dedicated 15A or 20A circuit from the DB, terminating in an aircon isolator (a weatherproof switch mounted near the indoor unit) rather than a regular socket. This is the safe, code-compliant way to wire an air-conditioner.

We install aircon power points and isolators as part of:

New aircon installation (coordinating with your aircon contractor if needed)
Aircon replacement (old isolator damaged, or upgrading to a higher-amperage model)
Renovation rewiring — see our Residential Rewiring Singapore page

If your current aircon spur is on a regular 13A socket (a common shortcut in older HDB flats), we strongly recommend upgrading to a proper 15A/20A isolator. It is a small job with a real safety benefit.

Our Power Point & Socket Service Process

Photo or model number — WhatsApp us a photo of the existing socket (if replacement) or a quick sketch of where you want a new one (if adding).
Site visit if needed — for new power points or whole-room conversions, we arrange a quick visit to confirm the cable route, wall type, and DB capacity.
Fixed quote — written quote before any work begins. No “we’ll see when we open it up” surprises.
Installation or repair — most socket jobs are done in 1–2 hours. We work clean, protect your furniture, and tidy up before we leave.
Test and demonstrate — we test the new or repaired socket under load before we leave, and show you the trip / isolator arrangement at the DB.
EMA-compliant, LEW-supported — every install is done to Singapore Standard CP5, with proper cable sizing, earthing, and (where required) a dedicated MCB at the DB.

Areas We Cover for Power Point & Socket Work

Islandwide Singapore, no travel surcharge. We regularly attend electrical repair calls in Tampines, Bedok, Sengkang, Punggol, Yishun, Woodlands, Jurong West, Jurong East, Bukit Batok, Toa Payoh, Ang Mo Kio, Hougang, Serangoon, Bishan, Clementi, Queenstown, Choa Chu Kang, Bukit Panjang, Pasir Ris, Kallang, Geylang, Marine Parade, Bukit Merah, Bukit Timah, Holland Village, and the East Coast. For landed properties and private estates, we have the same islandwide footprint and response times.

Why Homeowners Choose Us for Power Point & Socket Work

Licensed & LEW-endorsed — every install is reviewed by a Licensed Electrical Worker registered with the EMA.
EMA-approved parts only — Schneider, Legrand, Clipsal, or equivalent BS-1363 13A sockets. No unbranded, no “compatible” substitutes.
Clean, polite, on-time — drop sheets, shoe covers, and a tidy site are the default.
Same-day or next-day slots for most socket jobs.
HDB / condo / landed experience — we know the wall types, cable routes, and DB constraints of every common Singapore property.

FAQs

Can I just replace a socket myself?

Singapore law (Electricity Act, Cap. 89A) requires that fixed-wiring electrical work be carried out by a Licensed Electrical Worker. Replacing a like-for-like socket is generally treated as fixed-wiring work, so a licensed electrician is the legal standard. Beyond legality, a wrong connection at the back of a socket is one of the most common causes of house fires in Singapore — a $120 socket job is not worth the risk.

How long does it take to add a new power point?

A surface-trunking add is typically 1–2 hours. A concealed (chase-into-wall) add is 2–4 hours, plus making good. The total time depends on the wall material, the cable route, and whether we need to add a new MCB at the DB.

What brand of socket do you supply?

We supply Schneider, Legrand, Clipsal, and Hager — all of which are widely available in Singapore, all BS-1363 compliant, and all backed by manufacturer warranty. If you have already bought a particular brand or model, we are happy to install it.

Do I need to upgrade my DB to add a new power point?

Not always. If the existing circuit has spare capacity (a 20A circuit feeding 3 sockets can usually take a 4th without issue), we just spur off the existing circuit. If the circuit is full, we add a new MCB at the DB and run a fresh cable. We will tell you upfront which option your installation needs.

My socket sparked once — is it safe to keep using it?

Probably not, but it depends. A single small spark when unplugging a load is normal. A spark when plugging in (especially with a “pop” or flash) is a sign of loose back-terminal screws, a worn mechanism, or both. We recommend stopping use of that socket and getting it checked — a 30-minute visit is much cheaper than a house fire.

Can I get a 2-pin Euro socket for my imported appliance?

Yes — we can supply and fit 2-pin Schuko (Type F) or Euro (Type C) sockets on request. We will tell you upfront whether your specific appliance needs a step-down transformer, and we will always fit a properly earthed European-style outlet rather than a cheap ungrounded adaptor.
